| Weight | 500g |
|---|---|
| Datasheet | GEN-3001A03_datasheet |
| Dimensions | 115 x 139 x 40mm |
| Power cons | ≤3W |
| Audio codec | Opus, PCMU (G.711u),PCMA (G.711a), G.722 |
| Audio input | x1, Line/Micinput(Balanced,Switchable) |
| Network l/F | 10BASE-T/100BASE-TX,RJ45 Connector |
| Audio output | x1 (RCA Connector)，0dB |
| Manufacturer | SPON |
| Power output | 2*30W（Use DC 24V）,2*7W（Use POE/POE+） |
| Power source | DC24V，PoE (IEEE802.3af/at) |
| Control input | x4 |
| Control output | x1 ,Relay output/DC12Voutput switchable |
| Source category | IP Audio |
| Housing Material | Sheet Metal |
| Network protocol | TCP/IP,UDP,HTTP,RTP,RTSP,ARP,ICMP,NTP,SIP,ONVIF |
| Frequency response | 100~20KHz |
| Source subcategory | Receiver |
| Installation Manual | GEN-3001A03-Installation Manual |
| Operating temperature | -10℃ ~ +50℃ |
| Product Type | Audio sobre IP – Receptores |
| Potencia (W) | 2*30W（Use DC 24V）,2*7W（Use POE/POE+） |
| Tecnologia | IP / SIP |
| Alimentacion | POE |
| Material / Acabado | Metal |
