Sound Perfected, Noise Deflected
| Datasheet | TS-806A Datasheet |
|---|---|
| Gross Weight | 0.183 kg |
| Manufacturer | SPON |
| Pick-up Area | 10 square meters (adjustable) |
| Polar Pattern | Omnidirectional |
| Power Voltage | DC 12V |
| Source category | Surveillance Microphone |
| Connection Method | Supports three-wire, four-wire audio isolation output |
| Packed Dimensions | 114x100x49mm |
| Product Dimension | 86x86x17.3mm |
| Frequency Response | 20Hz to 20KHz |
| Protection Circuit | Power polarity reversal protection, ESD protection |
| Source subcategory | Analog Surveillance Microphone |
| Signal Output Amplitude | 2Vrms (@1KHz) / 5.6Vpp (@1KHz) |
| Signal Transmission Distance | 3000 meters (use shielded cable in complex electromagnetic environments) |
| Product Type | Micrófonos de vigilancia – Analógicos |
