Effcient Power, Excellent Performance
| Gain | 36.7dB |
|---|---|
| Datasheet | SAP-5402A50 Datasheet |
| Parameter | A35/A50/A75 |
| Interfaces | 2 line inputs, 2 line outputs, 2 power outputs |
| Gross Weight | 4.8Kg |
| Manufacturer | SPON |
| Input Impedance | Balanced 20KΩ / Unbalanced 10KΩ |
| Max Input Level | 3.5Vrms (13dBu) |
| Source category | Professional audio system |
| Surge Protection | Differential mode: 1KV, Common mode: 2KV |
| Input Sensitivity | 0.775Vrms / 1.414Vrms |
| Packed Dimensions | 573*368*123(mm) |
| Frequency Response | 20Hz-20KHz |
| Output Power (4Ω) | 700W×2/1000W×2/1200W×2 |
| Output Power (8Ω) | 350W×2 (1)/500W×2 (1)/700W×2 (1) |
| Output Power (BTL) | 700W×1 (2)/1000W×1 (2)/1200W×1 (2) |
| Power Supply Range | AC100～240V 50Hz～60Hz/AC 220V 50Hz/AC 220V 50Hz |
| Product Dimensions | 300.5 x 483.4 x 44.5(mm) |
| Source subcategory | Professional Amplifier |
| Installation Manual | SAP-5402A Installation Manual |
| Signal-to-Noise Ratio | ≥ 100dB(A-weighted) |
| Standby Power Consumption | < 5W/< 8W/< 8W |
| Total Harmonic Distortion | < 0.05% @1KHz 1/3 power output |
| Power Output Consumption (1/3) | 280W/430W/540W |
| Power Output Consumption (1/8) | 120W/180W/235W |
| Operating Temperature & Humidity | 0℃-45℃, ≤90%RH (non-condensing) |
| Product Type | Amplificadores profesionales |
| Potencia (W) | 120W/180W/235W, 280W/430W/540W |
