Total Control, Amplified Excellence
| Datasheet | NBS-2301P13 Datasheet |
|---|---|
| Interface | 1×RJ45 Ethernet Port, 1×SD Card Slot, 3×Mic Input (1/4” TS Jack), 2×Line Input (RCA Jack), 1×Line Output (RCA Jack), 3×Relay Input, 2×Relay Output, 1×4-Zone Speaker Output (100V), 1×4-Zone Speaker Output (100V), 2×Speaker Output (8-16Ω), 1×Speaker Output (100V), 1×Power Input |
| Dimensions | 483×430×88mm |
| Net Weight | 7.5kg |
| Audio Codec | MP2,MP3, PCM, ADPCM |
| Gross Weight | 9.5kg |
| Manufacturer | SPON |
| Power Supply | AC 100V-220V 50/60Hz |
| Speaker Output | 100V (Constant-Voltage) / 8-16Ω (Low-Impedance) |
| Source category | PA System |
| Network Protocol | TCP/IP, UDP, ARP, ICMP, IGMP,HTTP |
| Packed Dimensions | 560×530×170mm |
| Power Consumption | ≤170W / ≤320W / ≤420W / ≤650W / ≤800W |
| Frequency Response | 130-18kHz |
| Rated Power Output | 130W / 260W / 360W / 550W / 700W |
| Source subcategory | Amplifier |
| Installation Manual | NBS-2301 Installation Manual |
| Optional Accessories | IEC C13 Power Cord (US/EU/UK/AU) |
| Standard Accessories | 2×6-Pin Terminal Block Connector, 1×Installation Manual |
| S/N (Signal-to-Noise) Ratio | Mic Input 1: ≥66dB; Mic Input 2/3: ≥80dB; Line Input 1/2: ≥75dB |
| THD (Total Harmonic Distortion) | ≤0.5% at 1kHz, 1/2 rated output |
| Product Type | Amplificadores de línea |
| Potencia (W) | 130W / 260W / 360W / 550W / 700W |
| Tecnologia | IP / SIP |
