Sound Unleashed: Connectivity & Simplicity
| Cooling | Smart Temperature Control Fan Forced Cooling |
|---|---|
| Network | 10/100Mbps Adaptive |
| Datasheet | NXT-2201P36 Datasheet |
| Interface | 2 RJ45 Ports, 4 Alarm Inputs/Outputs, 4 Line Inputs, 1 Dynamic Microphone Input, 1 FM Antenna Connection, 1 AC220 Power Interface |
| Dimensions | 483*334*44mm (Length x Width x Height) |
| Net Weight | 4.87kg |
| Protection | Overcurrent, Short Circuit, Overheating Protection, AC Fuse |
| User Manual | NXT-2201P36/P72 User Manual |
| Manufacturer | SPON |
| Power Supply | AC220V/50Hz |
| Rated Current | 5A |
| Source category | Cloud PA System |
| Surge Protection | Power Supply: Common Mode 4KV, Differential Mode 2KV, Power Output: Common Mode 2KV |
| Frequency Response | 130Hz-18kHz |
| Output Power (RMS) | 360W / 720W |
| Source subcategory | Cloud Amplifier |
| Signal-to-Noise Ratio | MIC: ≥85dB, AUX: ≥95dB |
| Audio Sampling, Bitrate | 48kHz, 24bit |
| Total Harmonic Distortion | ≤0.5% (1kHz, 1/2 Power Output) |
| Working Temperature, Humidity | -10 °C~+50 °C, ≤90%RH (No Frost) |
| Product Type | Amplificadores en la nube |
